Attention!
Carbon Mini PC Upgrades (only for 16+512 variant) – Effective January 1, 2025
- Micro SD Card Slot Added
- 2.5Gbps Intel i226-V LAN Module Added
- HDMI Ports Replaced DP Port
Media Coverage
RAM and Storage Installation Tutorial
RAM and Storage Installation Tutorial
Real Life Performance Test
Works with almost all apps Adobe Photoshop, Illustrator, Animate, Premier Pro, After Effects, AutoCAD, Chrome, Microsoft Excel, Powerpoint, Word, etc.
Specifications
CPU:
- Intel Alder Lake N100 4C/4T 3.4GHz
Graphics:
- Intel UHD Graphics
Memory:
- DDR5 *1 SO-DIMM, Up to 16GB
Storage:
- NVME M.2: 128GB/256GB/512GB/1TB/2TB
- 2.5" SATA: Up to 2TB
Display:
- Triple Display: HDMI *1, DP *1, Type-C *1
Networking:
- RJ45: Gigabit Ethernet *2
- Wi-Fi + Bluetooth: 802.11 ac/b/g/n 2.4G/5G, Bluetooth 4.2
Shell Material:
- Plastic
Audio Output:
- 2-in-1 earphone
I/O Interface:
- USB 3.2 *2
- USB 2.0 *2
- Type-C 3.2 *1 (Data transfer/DP)
- HDMI *1
- DP *1
- RJ45 *2
- DC Jack *1
- 2-in-1 earphone *1
Power Adapter:
- 12V/2.5A
Dimensions:
- 116mm * 116mm * 46mm
Unit Weight:
- 300g
Software:
- OS: Windows, Linux
Included:
- Adapter
- SATA Connector
- VESA Mount
